The Mercury Racing® Revolution 4® XP propeller can be used to dial in with extreme precision the performance of multi-engine, stepped-bottom performance center consoles and single-engine bay boats. The standard-length exhaust tube helps reduce time-to-plane and provides stern lift at speed for maximum hull performance and an improved ride in a variety of conditions.
• Handcrafted by Mercury Racing Propeller Artisans
• The patented Mercury® Performance Vent System® (PVS) can be used to fine tune the amount of exhaust venting needed for quick planing in certain applications. In most cases Mercury Verado®, Mercury Pro XS®FourStroke and MerCruiser® sterndrive applications will run the Revolution 4® XP with all four vent holes plugged with solid PVS fittings.
Engine Type
Four-Stroke
Application
Bay, Center Console
Speed
55-90 MPH
HP Range
150HP to 450HP
Blades
4
Finish
PRO
Diameter
14.63"
Pitch Range
13" - 27.5"
View Part Numbers
Revolution 4XP.pdf
23.6 MBDOWNLOAD
Diameter
14.63"
Pitch Range
13" to 17"
Rotation
RH & LH
Finish
PRO
View Part Numbers
Product Details
|
Part Number |
Pitch |
Diameter |
Rotation |
|---|---|---|---|
| 8M0142110 | 13" | 15" | RH |
| 8M0142111 | 14" | 15" | LH |
| 8M0142112 | 14" | 15" | RH |
| 8M0142113 | 15" | 15" | LH |
| 8M0142114 | 15" | 15" | RH |
| 8M0142115 | 16" | 15" | LH |
| 8M0142116 | 16" | 15" | RH |
| 8M0142117 | 17" | 15" | LH |
| 8M0142118 | 17" | 15" | LH |
From planing performance to top-end speed, the Revolution 4 XP offers the best all-around performance for multiengine stepped-bottom outboard hulls. The Revolution 4 XP creates quicker planing because the long barrel design acts like a miniature trim tab. Thanks to an ample amount of tip cup, it also provides excellent handling through turns and rough seas.
We build bigger adventure fueled by gasoline and adrenaline. We are cutting edge. We can take you wide open.
Pitch
Diameter
Rotation
Finish
| Engine Type | Pitch | HP Range | Speed | Diameter | Rotation | Part Number |
|---|---|---|---|---|---|---|
| FourStroke | 17" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0142118 |
| FourStroke | 17" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0142117 |
| FourStroke | 16" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0142116 |
| FourStroke | 16" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0142115 |
| FourStroke | 15" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0142114 |
| FourStroke | 15" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0142113 |
| FourStroke | 14" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0142112 |
| FourStroke | 14" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0142111 |
| FourStroke | 13" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0142110 |
| FourStroke | 18" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113928 |
| FourStroke | 18" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113929 |
| FourStroke | 18.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113930 |
| FourStroke | 18.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113931 |
| FourStroke | 19" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113932 |
| FourStroke | 19" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113933 |
| FourStroke | 19.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113934 |
| FourStroke | 19.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113935 |
| FourStroke | 20" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113936 |
| FourStroke | 20" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113937 |
| FourStroke | 20.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113938 |
| FourStroke | 20.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113939 |
| FourStroke | 21" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113940 |
| FourStroke | 21" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113941 |
| FourStroke | 21.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113942 |
| FourStroke | 21.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113943 |
| FourStroke | 22" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113944 |
| FourStroke | 22" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113945 |
| FourStroke | 22.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113946 |
| FourStroke | 22.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113947 |
| FourStroke | 23" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113948 |
| FourStroke | 23" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113949 |
| FourStroke | 23.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113950 |
| FourStroke | 23.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113951 |
| FourStroke | 24" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113952 |
| FourStroke | 24" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113953 |
| FourStroke | 24.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113954 |
| FourStroke | 24.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113955 |
| FourStroke | 25" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113956 |
| FourStroke | 25" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113957 |
| FourStroke | 25.5" | 150-450 | 55-85 | 14.6" | Right Hand | 8M0113958 |
| FourStroke | 25.5" | 150-450 | 55-85 | 14.6" | Left Hand | 8M0113959 |
| FourStroke | 26 | 150-450 | 55-90 | 15" | Right Hand | 8M0173918 |
| FourStroke | 26.5 | 150-450 | 55-90 | 15" | Right Hand | 8M0173920 |
| FourStroke | 27 | 150-450 | 55-90 | 15" | Right Hand | 8M0173922 |
| FourStroke | 27.5 | 150-450 | 55-90 | 15" | Right Hand | 8M0173924 |
| FourStroke | 26 | 150-450 | 55-90 | 15" | Left Hand | 8M0173919 |
| FourStroke | 26.5 | 150-450 | 55-90 | 15" | Left Hand | 8M0173921 |
| FourStroke | 27 | 150-450 | 55-90 | 15" | Left Hand | 8M0173923 |
| FourStroke | 27.5 | 150-450 | 55-90 | 15" | Left Hand | 8M0173925 |
