With the introduction of the four-blade Bravo FS, bass, multispecies, bay boat, and center-console applications have realized much quicker planing compared to three-blade propellers. In addition, the Bravo FS provides a much smoother ride by improving the angle of attack. By switching to a Bravo FS, the engine can be raised as much as an inch, getting the most performance of any engine application and improving the driving experience. For some stepped hulls, the Bravo FS offers more bow lift than the Rev 4, improving ride quality because the boat rides on the steps correctly.
We’ve added four new models, ranging from 34-inch to 37-inch in pitch and designed specifically for our 4.6L V8 300R FourStroke outboards with the right-hand rotation: 1.75:1 gear ratio Sport Master gearcase.
Diameter
Pitch
Rotation
Finish
Engine Type | Pitch | HP Range | Speed | Diameter | Rotation | Part Number |
---|---|---|---|---|---|---|
FourStroke, Sterndrive | 20" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0090451 |
FourStroke, Sterndrive | 20.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0118469 |
FourStroke, Sterndrive | 21" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0090455 |
FourStroke, Sterndrive | 21.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0118471 |
FourStroke, Sterndrive | 22" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064450 |
FourStroke, Sterndrive | 22.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128332 |
FourStroke, Sterndrive | 23" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064468 |
FourStroke, Sterndrive | 23.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0152624 |
FourStroke, Sterndrive | 24" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064469 |
FourStroke, Sterndrive | 24.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128333 |
FourStroke, Sterndrive | 25" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064470 |
FourStroke, Sterndrive | 25.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0129397 |
FourStroke, Sterndrive | 26" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064471 |
FourStroke, Sterndrive | 26.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128334 |
FourStroke, Sterndrive | 27" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064472 |
FourStroke, Sterndrive | 28" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064473 |
FourStroke, Sterndrive | 28.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0129335 |
FourStroke, Sterndrive | 29" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064475 |
FourStroke, Sterndrive | 30" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064476 |
FourStroke, Sterndrive | 31" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064477 |
FourStroke, Sterndrive | 32" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0104417 |
FourStroke, Sterndrive | 33" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0104419 |
FourStroke, Sterndrive | 20" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0090453 |
FourStroke, Sterndrive | 21" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0090457 |
FourStroke, Sterndrive | 22" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071088 |
FourStroke, Sterndrive | 23" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071089 |
FourStroke, Sterndrive | 24" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071090 |
FourStroke, Sterndrive | 25" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071091 |
FourStroke, Sterndrive | 26" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071092 |
FourStroke, Sterndrive | 27" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071093 |
FourStroke, Sterndrive | 28" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071094 |
FourStroke, Sterndrive | 29" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071095 |
FourStroke, Sterndrive | 30" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071096 |
FourStroke, Sterndrive | 31" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071097 |
FourStroke, Sterndrive | 32" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0104418 |
Two-stroke, FourStroke, Sterndrive | 33" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0104420 |
Engine Type | Pitch | HP Range | Speed | Diameter | Rotation | Part Number |
---|---|---|---|---|---|---|
FourStroke, Sterndrive | 20" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0090451 |
FourStroke, Sterndrive | 20.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0118469 |
FourStroke, Sterndrive | 21" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0090455 |
FourStroke, Sterndrive | 21.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0118471 |
FourStroke, Sterndrive | 22" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064450 |
FourStroke, Sterndrive | 22.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128332 |
FourStroke, Sterndrive | 23" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064468 |
FourStroke, Sterndrive | 23.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0152624 |
FourStroke, Sterndrive | 24" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064469 |
FourStroke, Sterndrive | 24.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128333 |
FourStroke, Sterndrive | 25" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064470 |
FourStroke, Sterndrive | 25.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0129397 |
FourStroke, Sterndrive | 26" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064471 |
FourStroke, Sterndrive | 26.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0128334 |
FourStroke, Sterndrive | 27" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064472 |
FourStroke, Sterndrive | 28" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064473 |
FourStroke, Sterndrive | 28.5" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0129335 |
FourStroke, Sterndrive | 29" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064475 |
FourStroke, Sterndrive | 30" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064476 |
FourStroke, Sterndrive | 31" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0064477 |
FourStroke, Sterndrive | 32" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0104417 |
FourStroke, Sterndrive | 33" | 150-600 | 50-100 | 15.25" | Right Hand | 8M0104419 |
FourStroke, Sterndrive | 20" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0090453 |
FourStroke, Sterndrive | 21" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0090457 |
FourStroke, Sterndrive | 22" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071088 |
FourStroke, Sterndrive | 23" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071089 |
FourStroke, Sterndrive | 24" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071090 |
FourStroke, Sterndrive | 25" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071091 |
FourStroke, Sterndrive | 26" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071092 |
FourStroke, Sterndrive | 27" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071093 |
FourStroke, Sterndrive | 28" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071094 |
FourStroke, Sterndrive | 29" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071095 |
FourStroke, Sterndrive | 30" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071096 |
FourStroke, Sterndrive | 31" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0071097 |
FourStroke, Sterndrive | 32" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0104418 |
Two-stroke, FourStroke, Sterndrive | 33" | 150-600 | 50-100 | 15.25" | Left Hand | 8M0104420 |
